Specifications

Size Range: 2” – 24”
Maximum Temperature: Up to 230°C
Pressure Rating: Class 125
End Connections: Flanged to ANSI 150, PN16, JIS 10K

Standards

Design Codes: DIN, ASME, JIS
Face-to-Face Dimensions: ASME B16.10
Flange Dimensions: ASME B16.5

Materials

Body: Cast Iron ASTM A126B
Stem: 13% Cr Stainless Steel
Seat Ring: 13% Cr Stainless Steel
Wedge: Cast Iron ASTM A126B
Wedge Ring: 13% Cr Stainless Steel
